CITY ELEMENTS 200
Light and multifunctionality – for smart outdoor spaces
CITY ELEMENTS is a multifunctional lighting system suitable for meeting all requirements in urban space. Thanks to its modular elements, a variety of diameters and variable heights of up to nine metres – and even beyond – the system can be customised to the respective urban environment. Due to the large number of lighting variants and multifunctionalities, the CITY ELEMENTS is ideally suited for generating real added value.
For smart outdoor spaces of both today and tomorrow.
With three different diameters – 180 mm, 200 mm and 230 mm – the CITY ELEMENTS fits into any environment. The potential of the multifunctional luminaire extends far beyond pure illumination: The most innovative LED technology and individually combinable basic, intermediate and terminating elements offer a variety of additional features and power and water supply solutions for the urban requirements of today and tomorrow: whether loudspeakers, cameras, spotlights, WLAN, gobos, power and water connections, or charging infrastructures for e-mobility. Which elements are the right ones for you?
Related Products
Technical details
- LED Lifetime
- L90 B10 / 100.000h - TA <=25° C
- Rated luminous flux [lm]
-
City Elements 200-AA: 909 - 6187 lm City Elements 200-AA ZERO: 456 - 2964 lm City Elements 200-AR: 1241 - 7498 lm City Elements 200-AR ZERO: 1171 - 9960 lm City Elements 200-ARR: 5619 - 13399 lm City Elements 200-ARR ZERO: 5560 - 13277 lm City Elements 200-AD: 1141 - 14363 lm City Elements 200-BD: 1141 - 14363 lm - Ingress protection
- IP65
- IK-Value
- IK07
- IK-Value - PC
- IK10
- IK-Value - PMMA
- IK06
- ENEC
- For selected models, others on request
You will find further technical data if you have specified a variant.
Product overviewDimensions
