INSERT STAGE 2/3 SHADOW LIGHTS-2
26.41900.1V001 SPEAKER-MIT LAUTSPRECHER BOSE FS2SE
Pillar light made of aluminium tube, Ø 200 mm. Embedded base or flange plate for fastening. 2700 K / 3000 K. Protection rating I or II. BaseShield and SkyShield, to limit glare, available as accessories. Please note that for technical reasons, the ‘SkyShield’ and the ‘55° optics’ cannot be combined.
STAGE 1:
Fixed preconfigured stele in four different heights. Control per insert, optionally without dimming or with dimming via DALI, StepDIM or AstroDIM. For lighting paths (height 5000/6000/7000/8000 mm) with two inserts, streets (heights 6000/7000/8000 mm) with three inserts, boulevards (height 7000/8000 mm) with four inserts, squares (height 8000 mm) with five inserts.
STAGE 2:
Freely configurable stele with three available inserts: PREMIUM SPOT, PREMIUM WASH and PREMIUM WIDE. Insert installed in modules that can be rotated 360°. The spotlights are individually adjustable, vertically +40°/-45°, horizontally +30°/-30°. Control per insert. Additional inserts for CCTV, speakers and GOBO are available in the base element. Heights from 4200 mm to 8200 mm.
STAGE 3:
Freely configurable stele with three available inserts: PREMIUM SPOT, PREMIUM WASH and PREMIUM WIDE. Insert installed in modules that can be rotated 360°. The spotlights are freely adjustable vertically +40°/-45° and horizontally +30°/-30°. Control per spotlight via DMX / DALI possible, also available with Tunable White or RGBW in the future. Inserts for CCTV, speakers and GOBO are also available in the base element. Heights from 4200 mm to 8200 mm.
INSERT STAGE 2/3 SHADOW LIGHTS-2
INSERT SHADOW LIGHTS-2 SPEAKER
For mounting in the base element Stage 2/3
Housing made of aluminium, painted matt black RAL 9005
Equipped with speaker BOSE FS2SE
Cover black aluminum perforated plate
Power max. 16W
Frequency range 83 Hz - 19 kHz
Max. Sound pressure 105 dB-SPL
Radiation angle 145°H x 140°V
Ingress protection IP 55 (Speaker)
Connection and cable extension provided by others
(Please note manufacturer specifications)
Following versions are available:
- pre setting 100V - 16W or
- pre setting 16 Ohm - 16W
(please make your selection)
Technical specifications
- Version
- Insert - SPEAKER
- Net weight [kg]
- 6.11
Drawing
