Intermediate Element 180 BH

16.10310.0V002 LEERMODUL - HÖHE 800 MM


Intermediate Element 180 BH

Intermediate element 180 BH
Constructed from aluminium tube section ø 180 mm
Module length 800 mm
With inspection door
Colour: DB 703 or all RAL- (classic- single shades),
Hess-DB and Hess-Glimmer-colours.
RAL pearl-mica-metallic-shades on request.


Technical specifications

Ingress protection
IP65
Variant
BH - Spacer
Safety class
I , II
Height [mm]
800
Area exposed to wind
0,14 m²

Drawing


Downloads

Planning

Graphic with dimensions
