Illuminating bollard FERRARA 500

12.71512.0V001 1X LED E27

Square luminaire body made of aluminium. Luminaire enclosure made of PMMA, satin-finished. Rectangular bollard made of aluminium with flange plate. Protection rating I.


Illuminating bollard FERRARA 500

Illuminating bollard FERRARA 500
Housing made of aluminium
Cover of polyacrylic glass (PMMA) with frosted surface
Elec. equip.: 1xE27 socket for LED lamps (max. 250V)
Without lamp (LED Classic E27)
Ingress protection IP54, protection rating I
Total height 500 mm
With flange plate 210 x 210 x 12 mm
Connection: 3 x 2,5 mm² terminal in the base of the bollard
Colour: DB 703 or all RAL- (classic- single shades),
Hess-DB and Hess-Glimmer-colours.
RAL pearl-mica-metallic-shades on request.


Technical specifications

Ingress protection
IP54
Safety class
I
ULOR
70%
IK-Value
IK03
Height [mm]
500
Dimensions [mm]
150 x 150
Area exposed to wind
0,075 m²

Drawing


Downloads


Accessories

12.21005.0V001
ERDSTÜCK
CASSINO/FERRARA 500+900
